Artillery Sidewinder X1 Mintemp Bed Error

Bed temp errorAn all too common problem with the Artillery Sidewinder X1 3D printers is the message "Error: MINTEMP triggered, system stopped! Heater_ID: bed". The symptoms of the problem tend to be that you will be printing a project and at some random point during the print, the printer stops and throws this error. You clear the printer and restart the print, only to again have it at some random point stop with this error. The most common reason for this error is the wires to the heat bed thermistor break. This is due to the poor quality wires used for not only the thermistor, but for the heater power as well. I have had both fail.


Bed temp valueOne of the easiest ways to check for this is to power on the printer and click Tools > Heat > Extrude1 (if the Extrude1 Button shows) You may see the Bed button when clicking on Heat. If you do, that is the screen you want to be on. Now use the + (Add) and - (Dec) buttons to set an arbitrary heat value for the bed and let the bed heat to that temp. Next, watchthe bed temp circled on the screen in the image to the right while continually moving the heat bed forward and backwards along the Y axis. If at any point in the bed travel you see the measured value ( the number to the left of the forward slash) go to -15, then you are going to have this problem. The -15 value is seen when the thermistor connection is lost to the motherboard because of the broken wire.

The Fix

Now you say, how do I fix this problem? Should I replace the entire heat bed or is there something else I should do? One thing is, you would not replace the entire heat bed. The part that Artillery sells for this is the heater pad that has the thermistor integrated into it. I do not however recommend this solution. From my experience, it will fix your problem for a short time, but you will just end up with the same problem again down the road. I replaced my first heating pad while my machine was under warranty and had it fail again within 6 months because the new heater they sent used the same crappy wires and wire sleve as the original one. When this happened to me again, I needed a better solution. The actual heater and the thermistor on the pad were still good. It was just the wires that were bad. I decided that I would replace the thermistor wires which I did and later found that I had a good connection to the thermistor, but th bed would not heat. The power wires to the heating pad had also broken, so I ended up replacing both.

What is needed

This is a list of everything you will need:

  • Thin wires for the thermistor. I used an old USB cable I had laying around to salvage 2 small wires from. You want to have these a little longer than the original ones which I will explain later. The original wires are approximately 33 inches (83.8 centimeters), so make the new ones about 36 inches (91.4 centimeters).
  • Thicker wires for the power to the heater. I used an old PC power cable for this and pulled 2 of the wires from the casing. The original wires were approximately 24 inches (61 centimeters), so make the new ones about 27 inches (68.6 centimeters).
  • Heat shrink tubing. Youwill need 3 sizes. One size to fit the larger power wires and another to fit the smaller thermistor wires and a third large piece to cover the braided sleve where it connects to the heater at the bed.
  • crimp on lug2 crimp on lug or spade connectors for the power wires to replace the ones on the power wires that you are cutting off. These can be the cheap ones you get from the hardware or auto parts store.
  • thermistor connectorCut and save the small white connector that plugs into the motherboard for the thermistor with an inch or so of wire for splicing. If you have the connectors and proper crimp tool you can use that to crimp a new end on the thermistor, which would be better, but most people don't have those laying around.
  • A section of PET braided wire sleve about 25 inches (63.5 centimeters) and 3/8 inch (9.5 milimeters) diameter. This is to replace the original coated stiff wire sleve to make it more flexible.

The Procedure

cutting the bed wiresStart by cutting the wires and original braided sleve about 2 inches (5 centimeters) from the bed heater. Next, with a razor blade, carefully cut away about an inch of the braided sleve that is left to expose the wires that we will splice. Strip and solder on the new thermistor and power wires and put the heat shrink tubing over your connections. Next, slide on your section of braided sleve over all 4 of the new wires and slide the larger heat shrink tube down where your new splices are by the bed and shrink it down covering both the braided sleve and th original sleve. It is easiest to slide the wires through the braided sleve with no connectors on the ends as the connectors will bind in the sleve making it harder to get through. Once that is all together, splice on the connector for the thermistor. Make sure to slide a piece of heat shrink tube on both of the wires befor making the splice. I can't tell you the number of times I have for gotten that step. Then crimp on the 2 lug/spade connectors to the power wires. Last, feed the new wire assembly through the hole in the back of the printer and connect the wires for the power. One will go to the neutral (most likely white) power wire connecting to the power supply from the mains cord. The second wire will conect to the Solid State Relay (SSR). Now plug in the white thermistor connector to the motherboard and reassemble the bottom cover on the printer. You can now perform the same test as before, heating the bed to an arbitrary temp and then moving the bed back and forth along the Y axis to see if the temp on the display stays stable. If everything checks out, you are finished.

Related Images:

Benefits of inflatable hot tubs

Inflatable hot tubs have become increasingly popular in recent years due to their convenience, affordability, and many health benefits. Here are some of the top reasons why you might want to consider getting an inflatable hot tub for your home:

  1. Convenient: One of the biggest benefits of inflatable hot tubs is their convenience. Unlike traditional hot tubs, which require a permanent installation, inflatable hot tubs can be easily set up and taken down as needed. This makes them perfect for people who live in apartments or rentals, or who want the option to move their hot tub to a different location.
  2. Affordable: Inflatable hot tubs are also much more affordable than traditional hot tubs. While traditional hot tubs can cost thousands of dollars, inflatable hot tubs can be purchased for a fraction of the price. This makes them an accessible option for anyone who wants to enjoy the benefits of a hot tub without breaking the bank.
  3. Health benefits: Hot tubs have been shown to have numerous health benefits, including relieving muscle tension, reducing stress and anxiety, and improving sleep. Inflatable hot tubs offer all of these benefits, making them a great investment for your physical and mental well-being.
  4. Entertaining: Inflatable hot tubs are also a great way to entertain friends and family. Whether you're hosting a small gathering or a large party, an inflatable hot tub is a fun and unique addition that everyone will enjoy.

Overall, inflatable hot tubs offer a convenient, affordable, and enjoyable way to relax and unwind at home. If you're considering adding a hot tub to your home, an inflatable hot tub is a great option to consider.

Related Images:

Fixing the dreaded E02 error on your Bestway, Coleman or Lay-Z-Spa tub


If you have reached this page, you have undoubtedly been looking for a solution for the E02 error that is showing up on your pump/heater unit, AKA the egg, that is preventing you from relaxing in your hot tub right now. In this guide we'll go over the many things that cause this error to appear. We'll then show you what you need to do to fix it. Keep reading and we'll have your tub back up and running in no time.

Getting Prepared

For the procedures you will be doing in this article you will need some basic tools to perform the tasks. A phillips #2 and flat head screwdriver. For some things it may be easiest to have a cordless drill with a screwdiver attachment. A set of small pliers, both standard and needle nose may help for some things. A volt meter that can check continuity may also be needed. You should also have your black caps for your water ports handy as it may be necessary to disconnect the egg when the tub is filled. These prevent water from flowing out when the hoses are disconnected.

In the steps outlined here, there are many causes that can be fixed without the need to replace parts. Some of the solutions listed however will require replacing parts. The order in which we will cover the listed solutions is to cover the basics that don't require part replacements first to rule them out first. This will save you from purchasing parts you don't need and getting your tub back in order the cheapest way possible.

Whenever working on your egg, be sure to unplug the power cord from the mains line when doing any service. Only plug it in when told to do so. This is for your safety and to prevent further damage to your egg.

Part of being prepared is knowing what you are dealing with. So what does the E02 error actually mean. The E02 error simply means that the egg is not sensing proper water flow through the water's path. A number of things can cause this. Let's go through them now. We'll start with the easy ones first. After each one of these procedures, plug in the egg and give it a test run.

First Things First

Let's start with the simple and most obvious things to get them out of the way. If you try to start your water pump with no water in the tub or with the water level below the filter inlets, you will get this error. This only makes sense since the E02 error indicates a problem with water flow. If there is no water there, it cannot flow. As long as the water is above the two filter inlet pipes and at least half way to the outlet pipe, you should be able to get water to flow. It is best though to have the water above the outlet pipe. WIth that out of the way, lets get into the other causes of this error.

Dirty Filters

Believe it or not, your filters being dirty can actually cause this error. A buildup of dirt and other things on the filters can slow the flow of water through the system. If the water slows enough, the water flow sensor paddle will not move enough to trigger the sensor to tell the system that water is in fact moving. One EASY way to tell if this is your issue is to remove the filter housings and start your pump. If it runs and doesn't give you the E02 error, this is your problem. Simply hosing off the dirt and junk from the filters can restore the water flow to a normal level. If the filters are too dirty, they may require replacing.

Clogged Debris FIlter

Another thing that can restrict water flow is a dirt and junk buildup in the debris filter that is on the output side of the pump directly above one of the filter housings. On some models it is the piece that your ChemConnect attaches to. Remove this piece and look inside. If you see a bunch of junk in there, it is probably restricting the water flow enough to cause the error. The easiest way to clen this is to back flush this with your garden hose. In some cases you may need a brush to get it clean. Then re-attach it to the liner.

Dirt Buildup on the Flow Sensor Paddle

Sometimes, depending on conditions, the water flow sensor paddle can get a buildup of dirt and debris on it that will prevent it from moving to the correct position when water is flowing. This paddle is supposed to lift up and trigger a sensor to tell the system that water is moving when the pump is turned on. Start by putting your black stoppers on all of your debris screens inside the tub and disconnect the egg. This requires you to remove both filter housings to put these stoppers on. Look inside the top hose connector and you should see the flow sensor paddle hanging down. If you can see dirt and debris around that you need to clean it. First, flush water through the egg in both directions to help loosen and remove any other debris that may be hanging around inside. To do this , run your hose into the top port on your egg for one to two minutes as seen in the picture. Then switch the hose to the port just below that one and do the same thing from that end. Now look inside the top port again and see if the debris has cleared. Once flushed, re-attach the egg to the tub and re-test. Remember to remove the black stoppers from the ports inside the tub. Forgetting this will DEFINITELY cause an E02 error.

Crushed or Kinked Inlet/Outlet Pipe

A crushed or kinked inlet or outlet pipe can be caused from different things. One reason could be that your liner is low on air. The main reason for this is usually due to a kink in one of the hoses that goes through the liner from the egg because of a sag in the liner. The loss of air will allow the hose to bend which will restrict the water flow. Simply fill your liner with air can straighten the pipes out and if that was the issue you should be good. Other things such as pipes going soft over time can cause this. Another option to solve this would be to get a short piece of rigid pipe to fit inside this pipe to keep it from collapsing. This may be helpful to do to both the top and bottom water pipes.the pipe should fit inside the gray end and be long enough to go through the liner but not come out the other side. This length can be different depending on your tub model.

Limescale Buildup

If you live in an area with hard water you are no stranger to limescale. A limescale buildup on things can cause a number of different issues. If you cleaned out your debris filter in the previous steps and found white flaky bits in it, you most likely have a limescale problem. These bits can get on and into various things and cause problems. The image to the right, thanks to Dean Masters from the UK, is a heater unit that is caked with limescale. You can see how this could easily restrict water flow. One this bad in addition to restricting water flow can also trip the electrical line or the GFCI plug to your tub, which was the problem Dean was having. You may have heard of people talking about descaling their egg. A simple descaler can be seen to the left. The square tube with connectors is attached to the pump inlet and outlet and filled with cold water just a bit above the top tube. You will then need some sort of descaling solution. These can come in powder or liquid form. A common brand is made by a company called Oust and is designed to clean coffee kettles, irons and dishwashers. Some other brands are lime-away and CLR. Putting a good bit of this solution in the descaler and turning the pump and heater on for 15 to 30 minutes will break up and disolve the limescale buildup and get you back running quickly. If you are getting the E02 error immediately after turning on the pump, you may want to let this descaling solution sit for about an hour to see if it breaks up a little bit of the lime to get things flowing. Once it is flowing and you can turn the pump on, let it run for the 15 to 30 minutes and you should be set. If you live in an area of hard water you should do this a couple times per year to prevent these problems.

Broken, Stuck or Damaged Impeller or Impeller Shaft

The impeller is the part of the pump that actually makes the water move. The motor spins this and the paddles push the water. There are a number of things that can fail with regards to the impeller, one being the impeller shaft. The impeller shaft in the image to the right is the pin that goes through the center of the impeller with the two small black caps on it. Many of the impellers used in the egg have an impeller shaft that is made of ceramic. These shafts have been known to break on occasion. When this breaks, the impeller will not spin freely and can lead to a decrease or complete stop of the water flow. If the impeller is moving with a broken shaft the egg can be very noisy and making a rattling sound.

Another thing with the impeller can be a rusty or damaged magnet. To the left is an example of a rusty impeller magnet. When a magnet gets rusty, it gets weaker. When the magnet gets weaker it cannot spin as efficiently, or at all. In this case you will need to replace the impeller. Some of these have the magnet encased in plastic like the one to the left, and some have the magnet exposed like the one shown above. Replacemtns can be found on ebay, amazon and other online stores such as Some of these kits will also include the rubber o-ring seals. If you are taking your pump apart, why not replace them. An ounce of prevention is worth a pound of cure.

banner ad for spa parts

Damaged Water Flow Sensor

These pumps are equiped with a water flow sensor to tell the pump that water is actually moving through the system. The water flow sensor is a tube that has a small paddle that contains a small magnet that hangs in the water's path, and when water flows through the tube, the paddle is pushed upwards causing the magnet to trigger a magnetic switch. When the switch is triggered, it indicates that water is flowing. The way the system works with this sensor can trigger not only the E02 error, but it can also trigger an E01 error.

We'll start with the E01 error. When the pump is turned on, it immediately checks this sensor for a split second looking to see that it is not triggered before turning on the pump. If the system sees that the flow sensor is triggered immediately upon startup, it assumes that the paddle is stuck in the up position. With the paddle stuck in the up position, the system assumes that it cannot accurately detect water flow and will display an E01 error. If this is the case, sometimes a quick smack, not too hard, to the side of the pump will get the paddle to drop into the normal position. Another thing that can cause this is debris being stuck in the sensor, but if you did the flush in the earlier steps, this should not be an issue.

Now back to the original E02 issue. There are a few things that can cause the sensor to not trigger the magnetic switch. One of the main causes of this is broken plastic around the magnet that causes the magnet to get wet and rust. As a magnet gets rusty, it gets weaker and if it gets weak enough, it can't trigger the sensor mounted at the top. If this is the case, the paddle will need to be replaced. You will need to remove the cover to access the sensor. Start by putting your black stoppers on the inlet and outlet ports on the inside of the tub and disconnect the pump from the tub. Once disconnected, remove the screws on the lip about half way up the pump. Slowly lift the cover off, but watch for the ribbon cable that is attached. You may be able to just set the lid aside with the ribbon cable attached. If you need to disconnect it for any reason, grab the black connector on the sides and squeeze it, then pull the connector apart. Once the lid is off, look just behind the top outlet pipe and you will see the water flow sensor. Remove the four screws on the top of the sensor and lift the top off being careful of the sensor wire that is connected to it and the rubber o-ring seal under the lid. There will be a pin through the side that holds the paddle in place. Push that pin from the side being careful not to break it, and pull it out. Install the new paddle and replace the pin. Move the paddle back and forth to ensure that it moves freely. Now inspect the o-ring seal to see if it is damaged or looks worn. If so, it is best to replace it. I sell kits that come with the paddle and seal in one package. I also sell just the paddle separately. Click here to see my store for both. Once you have the paddle replaced and the o-ring inspected/replaced, re-assemble the flow sensor being careful not to knock the o-ring out of place and screw it back together. DO NOT overtighten the screws as you may damage the housing which will cause the seal to be weak and leak over time. Replace the cover being sure to connect the ribbon cable if you had it disconnected. Then re-connect the pump to your tub and give it a test. You should be back running.


By following these steps you should have been able to resolve any issue that would cause an E02 error. I hope thisarticle helped you and got you back to tubbing again. If you find any errors or just have questions, you can contact me here. Happy tubbing to all.

Related Images:

Bestway, Coleman, Lay-Z-Spa and Mspa LED lighting


hot tub LED lightingDo you own a Bestway, Coleman, Lay-Z-Spa or Mspa brand inflatable hot tub? Have you seen hot tubs lit at night with colored LED lighting and wondered how you can get that effect with your tub. In this article I will go over options for adding color changing LED lights to just about any one of these brands and models of airjet and hydrojet inflatable hot tubs. Get the night time glow and ambiance that you see in some of the more expensive hot tubs, from your cheaper model tub.

Lighting options and limitations

The hot tubs manufactured by Bestway which include the Coleman and Lay-Z-Spa line of tubs are some of the easiest tubs to add lighting to. The Mspa line of tubs have some limitations as far as the scope of this article, but I will discuss how to tell if your tub can handle one of the options I have. I will go through two different lighting options and show how they fit to the different tub models.

Intex LED lightThe first option I will touch on actually uses a light manufactured by Intex for their purespa line of tubs. This light uses a threaded fitting that it screws onto for the Intex tubs. Because of this, an adapter is needed to fit this to another brand of hot tub. There are three adapter options that can fit this light to a good number of the Bestway and Mspa brand tubs, but not all of the models will support this. This light can be purchased on my web store by clicking here.

The first adapter for this light will work with any of the Bestway, Coleman or Lay-Z-Spa tubs that use the ChemConnect chlorine dispenser. The ChemConnect is a simple push with a 1/4 twist to secure it to the tub. The adapter for this light uses the same push and twist fit that the ChemConnect has as seen in the picture to the right. This makes installing the light and swapping between that and the ChemConnect easy. You can purchase this adapter by clicking here.

The second adapter for this light works for any of the Bestway tubs that do not use the ChemConnect dispenser but have a removable water outlet debris filter as indicated in the picture to the left. The adapter screws on to the intex light and then threads on to the tub in place of the debris filter. You can purchase this adapter by clicking here.

The last adapter for this light, seen to the right, is designed for some of the Mspa branded tubs. This adapter is much like the last adapter for the Bestway tubs in that it replaces the water outlet debris filter. If your Mspa brand tub does not have a removable debris filter, unfortunately this adapter will not work and I have no other recommended options to allow a light to be fitted to this brand of tubs. You can purchase this adapter by clicking here.

The next lighting option will only work for Bestway, Coleman or Lay-Z-Spa brands of tubs. It uses a small remote controlled puck style light with an adapter that will fit the light to the front of the filter housing. The filter housing lock screw is removed and the light is threaded in it's place and acts as to hold the filter together. Because of the way this mounts, this will fit nearly all of the Bestway, Coleman and Lay-Z-Spa brands of tubs giving options to those that don't have a tub with a ChemConnect or a removable debris filter. You can purchase this light set by clicking here.

Next we have the Lay-Z-Spa light manufactured by Bestway, seen to the left. This light is much like the Intex light seen above with the second adapter mentioned in that it replaces the upper debris filter. It is simple to mount, but on some Bestway tubs, the water output debris filter is non-removable, in which case this light will not work. You can purchase this light from Amazon by clicking here.

The maority of the lighting options mentioned so far ar mostly meant for the AirJet line of tubs, but what options are there for HydroJet tub users. The light shown to the right is a multi-colored LED light Specifically made for the Bestway, Coleman or Lay-Z-Spa line of Hydrojet and HydroJet Pro tubs and it fits in place of one of the water jets for the tub. One big advantage of these lights vs the lights for the AirJet models is these lights are solely powered by water flow. This means no batteries or charging is required to enjoy its spectacular light show. Just insert in place of the water jet and that's it.

The last lighting option I will list will not be specific to a certain light, but more a category of lights. I like to call these sinkers and floaters. These are just as the name implies. Lights that sink to the bottom of the tub, and ones that float on top of the water. These types of lights will obviously work in any tub situation regardles of brand and model. I mentioned these last because they are the least attractive type of lighting. Various options for these can be found on Amazon, Ebay and other sites and stores.

The comparisons

Obviously some of the tubs may only have one option that will work, in which case there is not much of a need for a comparison. Some tubs however may have several options that will work, so here we'll do some comparisons on the models showing pros and cons to each to help you make an informed decision when choosing your lighting option for your tub.

Option Pros Cons
Intex Purespa LED light

click here to purchase
  1. Long battery life
  2. Mounting adapters for several brands and models
  3. Buttons on the device for control
  4. No remote to loose or damage
  5. 2 hour auto shut off to save batteries
  6. fits more than just the Bestway branded tubs
  1. Does not adapt to all tub models
Puck style filter mount light

click here to purchase
  1. Easy to mount
  2. 2 lights can be used (one on each filter)
  3. Compact
  1. Batteries are only rated for 10-12 hours of use
  2. Remote sometimes has trouble when light is under water
  3. Light will not work if remote is lost or damaged
Lay-Z-Spa light
  1. Easy to install
  2. 2 hour auto shut off to save batteries
  1. Only fits certain Bestway, Coleman or Lay-Z-Spa models
  2. Disables the ChemConnect on models that have it
Sinkers and Floaters
  1. Fits any brand or model of tub
  2. No special mounting needed
  3. Some are cheap
  1. Get in the way when in the tub
  2. Some are bulky


I hope this gave you some insight into different styles of lights and which one you should get for your tub. Now go out and put some flare in your new inflatable hot tub. Give it some color and ambiance for your parties.

Related Images:

Repairing yourBestway, Coleman or Lay-Z-Spa water flow sensor.

What is the water flow sensor.

water flow sensorThe water flow sensor is just as it's name says, it is use to tell a system that water is flowing. Seen to the right is the water flow sensor used in many of the Bestway, Coleman and Lay-Z-Spa branded inflatable hot tub models. These sensors are one way flow sensors meaning that they will only sense water flowing in one direction. Failure of this sensor is one of the causes of the dreaded E01 or E02 errors seen on the pump/heater unit of many of the listed brands of inflatable hot tubs.

How does the flow sensor work?

The operation of the water flow sensor is very simple. reed switchThere are three main components to the sensor. The first part is the main sensor housing. The housing has water inlet and outlet ports for the water to flow through. The second part is the magnetic reed switch, or proximity switch. This part is the small black tubular piece with the two wires coming off of it like the one seen to the right. When this piece senses a magnetic field, a small switch inside makes contact completing the circuit in the two wires. original sensor flapThe third part of the sensor, quite obviously, is the magnet. The magnet is housed in a small plastic paddle like the one seen to the left. When water is pushed through the sensor housing, this magnetic paddle will get pushed up near the proximity switch triggering it telling the system that water is in fact moving. This sensor is a one way sensor meaning that it will only sense the flow of water in one direction. Because of this, care must be taken to install this sensor in the correct direction for proper operation.

The main problem with these sensors.

The biggest problem with these sensors is that the magnetic paddles in them fail. The reason for this is because magnets can easily start to rust if exposed to water. rusty sensor flapWhy do magnets rust? Magnets work because they are made of ferrous metals which contain iron. Magnets need iron to attract, and iron rusts when exposed to oxygen and water. Rust reduces the attraction of a magnet. This is why the sensors fail when the magnet gets rusty. The original sensor paddles have the magnet inset into a hole in the center and then a dab of epoxy glue is put on top. Over time, the dab of epoxy can come loose from the paddle exposing the magnet to the water eventually causing it to rust and fail. The plastic around the magnet will start to crack because of the magnet swelling which allows more water in causing it to snowball into failure.

Inspecting your sensor.

pump/heater unitHow do you find out if your sensor has failed or is starting to fail. The first thing is to unplug your pump from the mains socket. Never work water stopperon your unit with the power plugged in. Now place your black rubber water stopper caps, seen on the left, over the water ports inside your tub. This is to prevent water flowing out of the flow sensor when you take the cap off. Next, remove the cover from your pump/heater unit by removing the six screws in the middle of the unit as indicated in the picture to the right. Once those screws are removed, carefully lift the top off being careful of the ribbon cable. inside pump/heaterNow, separate the black connectors on the ribbon cable slightly down from the control panel inside and set the cover to the side. In the picture to the left, the arrow points to the water flow sensor. Start by disconnecting the small plug on the two wires attached to the top of the sensor. Now remove the four screws from the top of the sensor and set them aside. cover with flapCarefully lift the top of the sensor off being careful not to loose the round o-ring seal under the cap. Inspect the plastic paddle under the cap looking for signs of cracks in the plastic, and signs of rust like the one shown to the right. If you see any of these things or other damage to the paddle, it is best to replace it. While you have the top off, you should also inspect the o-ring for any signs of wear. If there is even the slightest bit of wear on the o-ring, it is best to just replace it. Some would have you replace the entire water flow sensor assembly which can cost you between $50 and $75 US dollars just for the part. On top of that you would have to dismantle the unit even further to be able to remove the old one and install the new one. Why replace the whole sensor when you can just repair it.

Testing the sensor

To test the water flow sensor you will need a multimeter set to the continuity setting that will indicate an open or short condition. If your multimeter does not have a continuity setting you can put it on a resistance setting to show either infinite resistance or zero ohms (or near zero). You will also need two small pieces of stiff wire like in the picture to the right. The wires will be used to connect to the sensor to do the tests. The part that you will be testing with this is the mgnetic reed switch. The chances that this part would be bad are extremely slim. Unless there is physical damage to the black tube, this part should be considered good. Start by wrapping the small wires around the tip of the test probes and inserting them in the two holes in the connector. You will feel a bit of resistance when pushing the wires in, but they should be inserted enough to make a good connection with the connectors inside. Once connected, the water flow sensor should show an open or infinite resistance when the paddle is hanging down and a short or zero ohms when the paddle is in the upward position resting on the cover plate. If you don't read a shorted condition when the paddle is in the up position, you most likely have a problem with the paddle magnet. The sensor that senses the magnetic paddle is the black tube looking part that the wires connect to. It is extremely rare that that part will fail. If you have another small neodimium rare earth magnet (refrigerator magnets may not be strong enough) you can place it near where the paddle will hit the cover and see if the sensor triggers. If it does, then your paddle needs to be replaced. I sell both the replacement paddles as well as kits that include the paddle and the o-ring seal for the top of the sensor housing. Both the paddle and the kit version come with a replacement nylon pin to attach the paddle as many times these get broken. You can get both at my web store by clicking here. On the extremely rare chance that the sensor ( black tube) is bad, you may need to contact Bestway or purcase a new water flow sensor, but as mentioned, it is extremely rare that this part goes bad.

Repairing the sensor.

To repair the flow sensor you should by now know what parts you will need for the repair from the inspection you just did above. Whether you nee just the paddle, or the paddle and o-ring, we have you covered. If all you need is the water flow sensor paddle, this can be purchased from our store as a kit that now includes the retaining pin for $12.49 plus shipping by clicking here. If you also need the o-ring, we sell a kt that contains the paddle, retaining pin and the o-ring. These kits can be purchased from our store for $13.49 plus shipping by clicking here. If you decide that you want to go to someon else to purchase the paddle, there are some things that you need to watch out for. Be weary of the ones like the one on the right. In this style, the magnet is mounted directly on the top, completely exposed to the water. Because of this, the magnet will start to rust and fail significantly quicker than the ones that I sell in which the magnet is completely sealed in plasic. The other thing with paddles like this one is that people make these out of PLA plastic. This type of plastic has a lower melting point and if exposed to too much heat, it will start to deform. Once the plastic deforms, the magnet can pop out of it's hole causing another failure. Our paddles, seen on the left, are made completely from ABS plastic which is more flexible and has a lot higher melting point making it less prone to deforming and failure. Also the magnets on our sensors are completely encapsulated in plastic with little to no chance of the magnet touching water and rusting. Buy our parts with confidence.

Now on to replacing the sensor paddle. These sensors use a small nylon retaining pin to secure the paddle to the sensor cap. This can easily be removed by pushing on the back side of the pin, the side with the slot in it, with something flat. The pin should come out pretty easy. Simply pull the pin out enough to allow you to get the old paddle off. Put the new paddle in place and push the pin back through the hole. Our kits now include the retaining pin. It's that simple. Once you have that done, if needed, remove the old o-ring and drop the new one in it's place. Be sure to inspect and clean the channel that the o-ring sits in prior to installing the new one.


So that's it, you just repaired your water flow sensor for under $16 US dollars rather than spending $50 plus and all the extra time and effort

Related Images:
